Technical Solution
The trustworthy partner for IC design
Custom Design service
SoC Solution
SNST delivers end-to-end custom SoC design services—from spec-off to system integration, physical implementation, and verification.
Built on proprietary design expertise, customer-specific design engagements with industry partners,
and infrastructure solutions, we help clients gain a competitive edge in semiconductor innovation.
Design Service Flow
Flow
- SPEC
- Architecture Definition
- SoC Design Verification
- Prototyping & Validation
- SoC Implementation
- Evaluation Board &
S/W Setup
- SoC EV Test
- SoC Production(SCM)
- System Design
- System Production
Flow
- SPEC
- Architecture Definition
- SoC Design Verification
- Prototyping & Validation
- SoC Implementation
- Fab-in
- Fab-out
- Package
- SoC EV Test
- SoC Production(SCM)
- System Design
- System Production
Design Service Flow
|
Spec |
RTL |
Synthesis |
DFT |
Auto P&R |
Physical Verification & PSI Vertification |
Test Vector & Failure Analysis |
Maintenance |
Lv.0 |
|
|
|
|
|
|
|
|
Lv.1 |
|
|
|
|
|
|
|
|
Lv.2 |
|
|
|
|
|
|
|
|
Lv.3 |
|
|
|
|
|
|
|
|
High Performance
Physical Implementation
-
- Hardening for Computing Clusters
-
-
- Physical & Power-aware Logic Synthesis
-
- Logic Synthesis with physical information and power scenario
- Placement-Aware Multi-Bit Resister Banking
- Physically aware Clock Gating restructuring
Design for Testability
-
- Support-advanced DFT Solutions
-
- Low pin count test with serializer
- Power Aware DFT
- Test Fail Diagnosis
-
- Memory BIST(Build-in Self Test)
-
- Memory BIST/BIRA for higher SRAM yield
- Repair solution with eFuse & OTP
-
- Logic BIST
-
- Hardware based in-field testing method
- On-chip generated random patterns for safety and mission critical applications
-
- In-System test
-
- For safety-critical applications such as automotive, aerospace and medicine
- Use IST(In-System Test)controller through IJTAG network
- To access the chip during operation
-
- Scan(Advanced DFT skill)
-
- Scan test for improved test coverage for lower DPPM
- Stuck-At, Bridge, Transition, Path-delay, OCCT, Burn-in
-
- Boundary Scan
-
- Inter-chip connection test method for system level testing
-
- Physical DFT consider
-
- Physical Reordering and Repartitioning
Physical Design
-
- Accurate and robust timing analysis
-
- LVF based variability library
- Moment-based LVF to cope with non-Gaussian effect
- Parametic OCV method
- CCS/CCSN-based STA
- Statistical Rvia STA
- NP-Skewed corner STA for hold timing, min-pulse, and DCD check only
-
- Physical Optimization
-
- BEOL-aware delay optimization(BEOL resistance increase impacting path delay)
- Mixed DDB/MDB Flow
-
- Physical-aware Timing ECO
-
- Minimize physical side-effect for ECO
-
- MIM-aware Timing ECO
-
- Produce a single ECO file for Multiply Instantiated Module
- Accelerate multi-core CPU/GPU timing closure
Low Power
Dynamic Power Optimization
-
- Multi-supply Voltage&Voltage Island
- In-Ruch Current prevented power gating
- Clock/Memory-Gating
- Dynamic Voltage Frequency Scaling
- Vector-Driven Optimization
- Decap pre-placement method
- Merge or split ICG/Multi-bit flip-flop
- LowPower CTS(Concurrent Clock and Data Optimization)
Leakage Power Optimization
-
- Multi-Vth Optimization
- Gate-Length Biasing
- Sign-off Leakage Optimization
Low Power Verification
-
- Low power static rule check
- Power-aware Somulation
- Power-aware equivalence check
Power & Signal Integrity
Power Integrity Solution
-
- Power Plan based on Early Prototyping Analysis
- Dynamic Voltage Drop Analysis
- Static Power Analysis
- Power EM/BUMP Current
- P/G Resistance check
Signal Integrity Solution
-
- Signal EM
- Glitch Noise analysis
- Clock Jitter validation
- Duty-cycle distortion methodology
- Clock Propagation Check
- 3-row decap inverter on CTS
